Plate Steel ASTM A36 / SS400

Description Steel Plate ASTM A-36, also known as A36 or SS-400 Steel Plate, is a Hot Rolled structural quality steel plate used for a large variety of general construction and industrial applications. Mild Steel Plate ASTM A-36 is one of the most commonly used hot rolled general structural steel. Typical carbon steel materials, they are very cheap, excelling in weldability & machinability and they can be subjected to various heat treatments. Equivalents DIN 17100, ST 44-2, ASTM A36, ASTM A283 Grade D, EN S275/ BS 43A, AISI 1018, JIS 3101 SS-400 Availability Thickness: 1.2 mm – 100 mm Size: Width x Length 42 x 82 ( 1219 x 2438mm) , 52 x 202 ( 1524 x 6096mm) , 62 x 202 ( 1828 x 6096mm) Tabel Ukuran dan Berat Plat ASTM A-36 Product Tebal ( mm) PxL ( feet) Berat ( Kg) Mild steel 4mm 4 4× 8 = 93.32 Mild steel 4.5mm 4.5 4× 8 = 105 Mild steel 4.8mm 4.8 4× 8 = 112 Mild steel 5mm 5 4× 8 = 117 Mild steel 5.8mm 5.8 4× 8 = 135.32 Mild steel 6mm 6 4× 8 = 140 Mild steel 8mm 8 4× 8 = 187 Mild steel 9mm 9 4× 8 = 210 Mild steel 10mm 10 4× 8 = 233.3 Mild steel 11mm 11 4× 8 = 256.62 Mild steel 12mm 12 4× 8 = 280 Mild steel 13mm 13 4× 8 = 303.3 Mild steel 14mm 14 4× 8 = 326.62 Mild steel 15mm 15 4× 8 = 350 Mild steel 16mm 16 4× 8 = 373 Mild steel 18mm 18 4× 8 = 420 Mild steel 19mm 19 4× 8 = 443.3 Mild steel 20mm 20 4× 8 = 467 Mild steel 21mm 21 4× 8 = 490 Mild steel 22mm 22 4× 8 = 513.3 Mild steel 24mm 24 4× 8 = 560 Mild steel 25mm 25 4× 8 = 583.3 Mild steel 28mm 28 4× 8 = 653.24 Mild steel 30mm 30 4× 8 = 700 Mild steel 31mm 31 4× 8 = 723.3 Mild steel 32mm 32 4× 8 = 747 Mild steel 38mm 38 4× 8 = 887 Mild steel 40mm 40 4× 8 = 933.2 Mild steel 42mm 42 4× 8 = 980 Mild steel 45mm 45 4× 8 = 1050 Mild steel 50mm 50 4× 8 = 1167 Mild steel 65mm 65 4× 8 = 1516.5 Mild steel 75mm 75 4× 8 = 1750 Mild steel 80mm 80 4× 8 = 1870 Mild steel 85mm 85 4× 8 = 1983.1 Mild steel 90mm 90 4× 8 = 2100 Mild steel 100mm 100 4× 8 = 2333 Plat kapal 4.5mm 4.50 5” x 203 328 Plat kapal 6mm 6.00 5” x 203 438 Plat kapal 8mm 8.00 5” x 203 583 Plat kapal 9mm 9.00 5” x 203 656 Plat kapal 10mm 10.00 5” x 203 729 Plat kapal 12mm 12.00 5” x 203 876 Plat kapal 22mm 22.00 5” x 203 1604 Plat kapal 16mm 16.00 5” x 203 1167 Plat kapal 19mm 19.00 5” x 203 1386 Plat kapal 25mm 25.00 5” x 203 1822 Product Thk ( mm) Sheet Size Weight ( Kg) Marine Plate 4.5mm 4.50 6” x 203 394 Marine Plate 6mm 6.00 6” x 203 525 Marine Plate 8mm 8.00 6” x 203 700 Marine Plate 9mm 9.00 6” x 203 788 Marine Plate 10mm 10.00 6” x 203 875 Marine Plate 12mm 12.00 6” x 203 1050 Marine Plate 22mm 22.00 6” x 203 1400 Marine Plate 16mm 16.00 6” x 203 1664 Marine Plate 19mm 19.00 6” x 203 1926 Marine Plate 25mm 25.00 6” x 203 2188 Chemical Composition As per JIS G 3101, Carbon ( C) , Silicon ( Si) and Manganese ( Mn) content are not controlled. Phosphorus ( P) 0.05% Max and Sulphur ( S) 0.05% Max have to controlled below these levels. Mechanical Properties Density ( kg/ m3) : 7860 Young’ s Modulus ( GPa) : 190-210 Tensile Strength ( MPa) : 400 – 510 MPa Yield Strength ( MPa) : 205-245 MPa Poisson’ s ratio : 0.26 Hardness Brinell Hardness ( HB) 160 Melting Point Melting point of SS400 is 1430 Degree Celsius Workability Easy to Weld, Cut, Form and Machine Applications Base plates, Bridge, gussets, liners, road plates, trench covers, etc.
